Vehicle specifications
Ferrari 750 Monza 750 Monza
Compare all 1 engine versions of the Ferrari 750 Monza 750 Monza, then open the technical data for the exact drivetrain and production year.
Vehicle photos
1 of 4
View larger
Choose a drivetrain
Engine versions
Select a row to update the key figures and detailed specifications below.
1 versions · 1 Gasoline
| Engine | Fuel | Power | Production |
|---|---|---|---|
| 3.0 (260 KM) Selected | Gasoline | 260 KM | 1954 |
No matching engine version
Try a model number, power figure or clear the fuel filter.
Selected engine version
3.0 (260 KM)
Gasoline · 1954
- Engine power
- 260KM
- Engine displacement
- 2,999cm³
- Fuel type
- Gasoline
- Maximum speed
- 264km/h
On this page
Basic version information
Ferrari 750 Monza 750 Monza- Brand
- Ferrari
- Model
- 750 Monza
- Version
- 750 Monza
- Engine
- 3.0 (260 KM)
- Engine type
- Combustion engine
- Number of doors
- 2
- Start of production
- 1954
- End of production
- 1954
- Body type
- Roadster
- Number of seats
- 2
- Fuel type
- Gasoline
Performance
- Maximum speed
- 264 km/h
- Fuel consumption - Combined cycle
- 26 l/100 km
Vehicle history report
Check this vehicle's history
A VIN report can help confirm the exact engine, equipment, mileage records and reported damage before you buy.
Engine
- Engine position
- Front, Longitudinal
- Engine displacement
- 2999 cm³
- Maximum engine speed
- 6000 obr./min
- Fuel injection system
- Carburetor
- Engine type
- Naturally aspirated engine
- Valvetrain
- DOHC
- Engine configuration
- Inline
- Number of cylinders
- 4
- Cylinder bore
- 103 mm
- Piston stroke
- 90 mm
- Compression ratio
- 8.6
- Number of valves per cylinder
- 2
- Engine oil capacity
- 16 l
- Power
- 260 KM
Volume and weight
- Fuel tank
- 150 l
- Curb weight
- 760 kg
Vehicle dimensions
- Wheelbase
- 2250 mm
- Front track
- 1278 mm
- Rear track
- 1284 mm
- Ground clearance
- 140 mm
- Turning circle
- 10 m
Drivetrain, Brakes and suspension
- Drive
- Rear-wheel drive
- Number of gears
- 5
- Front suspension
- Coil spring
- Rear suspension
- De-Dion suspension, Leaf springs
- Front brakes
- Drum
- Rear brakes
- Drum
- Steering system
- Worm gearbox
- Tire size
- 185/80 R16
- Rim size
- 5J x 16
- ABS
- no
