Specifications KGM Korando
Vehicle photos
Basic information
| Brand | KGM |
|---|---|
| Model | Korando |
| Version | Korando |
| Engine power | – |
| Years of production | 2023 r. – |
| Body type | SUV |
| Number of doors | 5 |
| Number of seats | 5 |
Choose engine version, to see Vehicle specifications
Basic version information
| Brand | KGM |
|---|---|
| Model | Korando |
| Version | Korando |
| Engine | e-Motion 61.5 kWh (190 KM) |
| Engine type | BEV (Battery Electric Vehicle) |
| Number of doors | 5 |
| Start of production | 2023 r. |
| Body type | SUV |
| Number of seats | 5 |
| Fuel type | Electricity |
HISTORY OF VEHICLE
Buying a car? Check its history before making a decision!
» Click to check the vehicle historyPerformance
| Maximum speed | 156 km/h |
|---|---|
| Acceleration 0-100 km/h | 8.5 s |
| Battery gross capacity | 61.5 kWh |
| Net battery capacity | 55.3 kWh |
| Electric range measurement standard | WLTP |
| All-electric range | 339-346 km |
| Energy consumption measurement standard | WLTP |
| Average energy consumption | 16.8-19.4 kWh/100 km |
Engine
| Max electric motor power | 190 KM |
|---|---|
| Electric motor torque | 360 Nm |
| Electric motor position | Front axle, Transverse |
| System power | 190 KM |
| System torque | 360 Nm |
Volume and weight
| Minimum trunk capacity | 551 l |
|---|---|
| Maximum trunk capacity | 1248 l |
| Curb weight | 1765-1822 kg |
| Gross weight | 2250 kg |
| Braked trailer load (12% slope start) | 1500 kg |
| Trailer load without brakes | 500 kg |
Vehicle dimensions
| Length | 4465 mm |
|---|---|
| Width | 1870 mm |
| Height | 1635 mm |
| Wheelbase | 2675 mm |
| Front track | 1590 mm |
| Rear track | 1610 mm |
| Ground clearance | 169 mm |
| Approach angle | 19.5 ° |
| Departure angle | 25 ° |
| Ramp angle | 15 ° |
| Front overhang | 922 mm |
| Rear overhang | 868 mm |
| Turning circle | 10.7 m |
Drivetrain, Brakes and suspension
| Drive | Front-wheel drive |
|---|---|
| Number of gears | 1 |
| Front suspension | Independent McPherson type |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated disc |
| Rear brakes | Disc |
| ABS | yes |
| Steering system | Rack-and-pinion |
| Power steering | Electric power steering |
| Tire size | 215/65 R17 |
| Rim size | 6.5J x 17 |
Basic version information
| Brand | KGM |
|---|---|
| Model | Korando |
| Version | Korando |
| Engine | 1.5 T-GDI (163 KM) |
| Engine type | Combustion engine |
| Number of doors | 5 |
| Start of production | 2023 r. |
| Body type | SUV |
| Number of seats | 5 |
| Fuel type | Gasoline |
HISTORY OF VEHICLE
Buying a car? Check its history before making a decision!
» Click to check the vehicle historyPerformance
| Maximum speed | 191 km/h |
|---|---|
| Fuel consumption - Combined cycle | 7.5-7.6 l/100 km |
| Emission standard | Euro 6d |
| CO2 measurement standard | WLTP |
| CO2 emissions | 171 g/km |
Engine
| Engine model / code | G15DTF |
|---|---|
| Engine position | Front, Transverse |
| Engine displacement | 1497 cm³ |
| Fuel injection system | Direct injection |
| Engine type | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine configuration | Inline |
| Number of cylinders | 4 |
| Cylinder bore | 76 mm |
| Piston stroke | 82.5 mm |
| Compression ratio | 9.5 |
| Number of valves per cylinder | 4 |
| Engine oil capacity | 4.5 l |
| Coolant capacity | 7 l |
Volume and weight
| Fuel tank | 50 l |
|---|---|
| Minimum trunk capacity | 551 l |
| Maximum trunk capacity | 1248 l |
| Curb weight | 1442 kg |
| Gross weight | 1980 kg |
| Braked trailer load (12% slope start) | 1500 kg |
| Trailer load without brakes | 750 kg |
Vehicle dimensions
| Length | 4450 mm |
|---|---|
| Width | 1870 mm |
| Height | 1630 mm |
| Wheelbase | 2675 mm |
| Front track | 1590 mm |
| Rear track | 1610 mm |
| Ground clearance | 180 mm |
| Approach angle | 18 ° |
| Departure angle | 24.5 ° |
| Ramp angle | 15.9 ° |
| Front overhang | 910 mm |
| Rear overhang | 865 mm |
| Turning circle | 10.7 m |
Drivetrain, Brakes and suspension
| Drive | Front-wheel drive |
|---|---|
| Number of gears | 6 |
| Front suspension | Independent McPherson type |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated disc |
| Rear brakes | Disc |
| ABS | yes |
| Steering system | Rack-and-pinion |
| Power steering | Electric power steering |
| Tire size | 215/65 R18 |
| Rim size | 18 |
Basic version information
| Brand | KGM |
|---|---|
| Model | Korando |
| Version | Korando |
| Engine | 1.5 T-GDI (163 KM) Automatic |
| Engine type | Combustion engine |
| Number of doors | 5 |
| Start of production | 2023 r. |
| Body type | SUV |
| Number of seats | 5 |
| Fuel type | Gasoline |
HISTORY OF VEHICLE
Buying a car? Check its history before making a decision!
» Click to check the vehicle historyPerformance
| Maximum speed | 189 km/h |
|---|---|
| Fuel consumption - Combined cycle | 8 l/100 km |
| Emission standard | Euro 6d |
| CO2 measurement standard | WLTP |
| CO2 emissions | 182 g/km |
Engine
| Engine model / code | G15DTF |
|---|---|
| Engine position | Front, Transverse |
| Engine displacement | 1497 cm³ |
| Fuel injection system | Direct injection |
| Engine type | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine configuration | Inline |
| Number of cylinders | 4 |
| Cylinder bore | 76 mm |
| Piston stroke | 82.5 mm |
| Compression ratio | 9.5 |
| Number of valves per cylinder | 4 |
| Engine oil capacity | 4.5 l |
| Coolant capacity | 7 l |
Volume and weight
| Fuel tank | 50 l |
|---|---|
| Minimum trunk capacity | 551 l |
| Maximum trunk capacity | 1248 l |
| Curb weight | 1469 kg |
| Gross weight | 2005 kg |
| Braked trailer load (12% slope start) | 1500 kg |
| Trailer load without brakes | 500 kg |
Vehicle dimensions
| Length | 4450 mm |
|---|---|
| Width | 1870 mm |
| Height | 1630 mm |
| Wheelbase | 2675 mm |
| Front track | 1590 mm |
| Rear track | 1610 mm |
| Ground clearance | 180 mm |
| Approach angle | 18 ° |
| Departure angle | 24.5 ° |
| Ramp angle | 15.9 ° |
| Front overhang | 910 mm |
| Rear overhang | 865 mm |
| Turning circle | 10.7 m |
Drivetrain, Brakes and suspension
| Drive | Front-wheel drive |
|---|---|
| Number of gears | 6 |
| Front suspension | Independent McPherson type |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated disc |
| Rear brakes | Disc |
| ABS | yes |
| Steering system | Rack-and-pinion |
| Power steering | Electric power steering |
| Tire size | 215/65 R18 |
| Rim size | 18 |
Basic version information
| Brand | KGM |
|---|---|
| Model | Korando |
| Version | Korando |
| Engine | 1.5 T-GDI (163 KM) 4WD |
| Engine type | Combustion engine |
| Number of doors | 5 |
| Start of production | 2023 r. |
| Body type | SUV |
| Number of seats | 5 |
| Fuel type | Gasoline |
HISTORY OF VEHICLE
Buying a car? Check its history before making a decision!
» Click to check the vehicle historyPerformance
| Maximum speed | 191 km/h |
|---|---|
| Fuel consumption - Combined cycle | 8.1 l/100 km |
| Emission standard | Euro 6d |
| CO2 measurement standard | WLTP |
| CO2 emissions | 185 g/km |
Engine
| Engine model / code | G15DTF |
|---|---|
| Engine position | Front, Transverse |
| Engine displacement | 1497 cm³ |
| Fuel injection system | Direct injection |
| Engine type | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine configuration | Inline |
| Number of cylinders | 4 |
| Cylinder bore | 76 mm |
| Piston stroke | 82.5 mm |
| Compression ratio | 9.5 |
| Number of valves per cylinder | 4 |
| Engine oil capacity | 4.5 l |
| Coolant capacity | 7 l |
Volume and weight
| Fuel tank | 50 l |
|---|---|
| Minimum trunk capacity | 551 l |
| Maximum trunk capacity | 1248 l |
| Curb weight | 1508 kg |
| Gross weight | 2045 kg |
| Braked trailer load (12% slope start) | 1500 kg |
| Trailer load without brakes | 750 kg |
Vehicle dimensions
| Length | 4450 mm |
|---|---|
| Width | 1870 mm |
| Height | 1630 mm |
| Wheelbase | 2675 mm |
| Front track | 1590 mm |
| Rear track | 1610 mm |
| Ground clearance | 180 mm |
| Approach angle | 18 ° |
| Departure angle | 24.5 ° |
| Ramp angle | 15.9 ° |
| Front overhang | 910 mm |
| Rear overhang | 865 mm |
| Turning circle | 10.7 m |
Drivetrain, Brakes and suspension
| Drive | All-wheel drive (4x4) |
|---|---|
| Number of gears | 6 |
| Front suspension | Independent McPherson type |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated disc |
| Rear brakes | Disc |
| ABS | yes |
| Steering system | Rack-and-pinion |
| Power steering | Electric power steering |
| Tire size | 215/65 R18 |
| Rim size | 18 |
Basic version information
| Brand | KGM |
|---|---|
| Model | Korando |
| Version | Korando |
| Engine | 1.5 T-GDI (163 KM) 4WD Automatic |
| Engine type | Combustion engine |
| Number of doors | 5 |
| Start of production | 2023 r. |
| Body type | SUV |
| Number of seats | 5 |
| Fuel type | Gasoline |
HISTORY OF VEHICLE
Buying a car? Check its history before making a decision!
» Click to check the vehicle historyPerformance
| Maximum speed | 189 km/h |
|---|---|
| Fuel consumption - Combined cycle | 8.6 l/100 km |
| Emission standard | Euro 6d |
| CO2 measurement standard | WLTP |
| CO2 emissions | 197 g/km |
Engine
| Engine model / code | G15DTF |
|---|---|
| Engine position | Front, Transverse |
| Engine displacement | 1497 cm³ |
| Fuel injection system | Direct injection |
| Engine type | Turbocharger, Intercooler |
| Valvetrain | DOHC |
| Engine configuration | Inline |
| Number of cylinders | 4 |
| Cylinder bore | 76 mm |
| Piston stroke | 82.5 mm |
| Compression ratio | 9.5 |
| Number of valves per cylinder | 4 |
| Engine oil capacity | 4.5 l |
| Coolant capacity | 7 l |
Volume and weight
| Fuel tank | 50 l |
|---|---|
| Minimum trunk capacity | 551 l |
| Maximum trunk capacity | 1248 l |
| Curb weight | 1537 kg |
| Gross weight | 2075 kg |
| Braked trailer load (12% slope start) | 1500 kg |
| Trailer load without brakes | 500 kg |
Vehicle dimensions
| Length | 4450 mm |
|---|---|
| Width | 1870 mm |
| Height | 1630 mm |
| Wheelbase | 2675 mm |
| Front track | 1590 mm |
| Rear track | 1610 mm |
| Ground clearance | 180 mm |
| Approach angle | 18 ° |
| Departure angle | 24.5 ° |
| Ramp angle | 15.9 ° |
| Front overhang | 910 mm |
| Rear overhang | 865 mm |
| Turning circle | 10.7 m |
Drivetrain, Brakes and suspension
| Drive | All-wheel drive (4x4) |
|---|---|
| Number of gears | 6 |
| Front suspension | Independent McPherson type |
| Rear suspension | Independent multi-link suspension |
| Front brakes | Ventilated disc |
| Rear brakes | Disc |
| ABS | yes |
| Steering system | Rack-and-pinion |
| Power steering | Electric power steering |
| Tire size | 215/65 R18 |
| Rim size | 18 |
