Vehicle specifications
Dodge Caravan V
Compare all 4 engine versions of the Dodge Caravan Caravan V, then open the technical data for the exact drivetrain and production year.
Vehicle history report
Buying a used Dodge Caravan V? Check the history of the exact car
A VIN report can help confirm the exact engine, equipment, mileage records and reported damage before you buy.
Vehicle photos
1 of 2
View larger
Choose a drivetrain
Engine versions
Select a row to update the key figures and detailed specifications below.
4 versions · 4 Gasoline
| Engine | Fuel | Power | Production |
|---|---|---|---|
| 4.0 V6 (257 KM) Automatic Selected | Gasoline | 257 KM | 2008–2010 |
| 3.8 V6 (193 KM) Automatic Selected | Gasoline | 193 KM | 2008–2010 |
| 3.8 V6 (200 KM) Automatic Selected | Gasoline | 200 KM | 2008–2010 |
| 3.3 V6 (178 KM) Automatic Selected | Gasoline | 178 KM | 2008–2010 |
No matching engine version
Try a model number, power figure or clear the fuel filter.
Selected engine version
4.0 V6 (257 KM) Automatic
Gasoline · 2008–2010
- Engine power
- 257 KM
- Torque
- 350 Nm
- Engine displacement
- 3,952 cm³
- Fuel type
- Gasoline
- Maximum speed
- 179 km/h
On this page
Check vehicle history
Basic version information
Dodge Caravan Caravan V- Brand
- Dodge
- Model
- Caravan
- Version
- Caravan V
- Engine
- 4.0 V6 (257 KM) Automatic
- Engine type
- Combustion engine
- Number of doors
- 5
- Start of production
- 2008
- End of production
- 2010
- Body type
- Minivan
- Number of seats
- 7
- Fuel type
- Gasoline
Performance
- Maximum speed
- 179 km/h
- Fuel consumption - Urban cycle
- 14.7 l/100 km
- Fuel consumption - Extra-urban cycle
- 10.2 l/100 km
- Fuel consumption - Combined cycle
- 12.4 l/100 km
- Emission standard
- Euro 4
Engine
- Engine position
- Front, Transverse
- Engine displacement
- 3952 cm³
- Maximum engine speed
- 6000 obr./min
- Fuel injection system
- Multi-point injection
- Engine type
- Naturally aspirated engine
- Valvetrain
- SOHC
- Engine configuration
- V-shaped
- Number of cylinders
- 6
- Cylinder bore
- 96 mm
- Piston stroke
- 91 mm
- Compression ratio
- 10.3
- Number of valves per cylinder
- 4
- Engine oil capacity
- 5.2 l
- Coolant capacity
- 12.6 l
- Power
- 257 KM @ 6000 obr./min
- Torque
- 350 Nm @ 4200 obr./min
Volume and weight
- Fuel tank
- 76 l
- Aerodynamic drag coefficient (Cx)
- 0.33
- Minimum trunk capacity
- 2350 l
- Maximum trunk capacity
- 3981 l
- Curb weight
- 2047 kg
- Braked trailer load (12% slope start)
- 1633 kg
Vehicle dimensions
- Length
- 5144 mm
- Width
- 2000 mm
- Height
- 1750 mm
- Wheelbase
- 3078 mm
- Front track
- 1663 mm
- Rear track
- 1645 mm
- Ground clearance
- 155 mm
- Approach angle
- 14.3 °
- Departure angle
- 18.7 °
- Ramp angle
- 13.9 °
- Turning circle
- 11.92 m
Drivetrain, Brakes and suspension
- Drive
- Front-wheel drive
- Number of gears
- 6
- Front brakes
- Ventilated disc
- Rear brakes
- Disc
- Tire size
- 225/65 R16
- Rim size
- 16
- ABS
- yes
Selected engine version
3.8 V6 (193 KM) Automatic
Gasoline · 2008–2010
- Engine power
- 193 KM
- Torque
- 305 Nm
- Engine displacement
- 3,778 cm³
- Fuel type
- Gasoline
- Maximum speed
- 193 km/h
On this page
Check vehicle history
Basic version information
Dodge Caravan Caravan V- Brand
- Dodge
- Model
- Caravan
- Version
- Caravan V
- Engine
- 3.8 V6 (193 KM) Automatic
- Engine type
- Combustion engine
- Number of doors
- 5
- Start of production
- 2008
- End of production
- 2010
- Body type
- Minivan
- Number of seats
- 7
- Fuel type
- Gasoline
Performance
- Maximum speed
- 193 km/h
- Fuel consumption - Urban cycle
- 18.8 l/100 km
- Fuel consumption - Extra-urban cycle
- 9.1 l/100 km
- Fuel consumption - Combined cycle
- 12.7 l/100 km
- Emission standard
- Euro 4
Engine
- Engine position
- Front, Transverse
- Engine displacement
- 3778 cm³
- Maximum engine speed
- 5600 obr./min
- Fuel injection system
- Multi-point injection
- Engine type
- Naturally aspirated engine
- Valvetrain
- OHV
- Engine configuration
- V-shaped
- Number of cylinders
- 6
- Cylinder bore
- 96 mm
- Piston stroke
- 87 mm
- Compression ratio
- 9.6
- Number of valves per cylinder
- 2
- Engine oil capacity
- 4.7 l
- Coolant capacity
- 12.6 l
- Power
- 193 KM @ 5200 obr./min
- Torque
- 305 Nm @ 4000 obr./min
Volume and weight
- Fuel tank
- 76 l
- Aerodynamic drag coefficient (Cx)
- 0.33
- Curb weight
- 2025 kg
- Gross weight
- 2775 kg
Vehicle dimensions
- Length
- 5177 mm
- Width
- 2000 mm
- Height
- 1750 mm
- Wheelbase
- 3078 mm
- Front track
- 1663 mm
- Rear track
- 1645 mm
- Ground clearance
- 155 mm
- Approach angle
- 14.3 °
- Departure angle
- 18.7 °
- Ramp angle
- 13.9 °
- Turning circle
- 11.92 m
Drivetrain, Brakes and suspension
- Drive
- Front-wheel drive
- Number of gears
- 6
- Front brakes
- Ventilated disc
- Rear brakes
- Disc
- Tire size
- 225/65 R16
- Rim size
- 16
- ABS
- yes
Selected engine version
3.8 V6 (200 KM) Automatic
Gasoline · 2008–2010
- Engine power
- 200 KM
- Torque
- 312 Nm
- Engine displacement
- 3,778 cm³
- Fuel type
- Gasoline
- Maximum speed
- 179 km/h
On this page
Check vehicle history
Basic version information
Dodge Caravan Caravan V- Brand
- Dodge
- Model
- Caravan
- Version
- Caravan V
- Engine
- 3.8 V6 (200 KM) Automatic
- Engine type
- Combustion engine
- Number of doors
- 5
- Start of production
- 2008
- End of production
- 2010
- Body type
- Minivan
- Number of seats
- 7
- Fuel type
- Gasoline
Performance
- Maximum speed
- 179 km/h
- Fuel consumption - Urban cycle
- 14.7 l/100 km
- Fuel consumption - Extra-urban cycle
- 10.2 l/100 km
- Fuel consumption - Combined cycle
- 12.4 l/100 km
- Emission standard
- Euro 4
Engine
- Engine position
- Front, Transverse
- Engine displacement
- 3778 cm³
- Maximum engine speed
- 5600 obr./min
- Fuel injection system
- Multi-point injection
- Engine type
- Naturally aspirated engine
- Valvetrain
- OHV
- Engine configuration
- V-shaped
- Number of cylinders
- 6
- Cylinder bore
- 96 mm
- Piston stroke
- 87 mm
- Compression ratio
- 9.6
- Number of valves per cylinder
- 2
- Engine oil capacity
- 4.7 l
- Coolant capacity
- 12.6 l
- Power
- 200 KM @ 5200 obr./min
- Torque
- 312 Nm @ 4000 obr./min
Volume and weight
- Fuel tank
- 76 l
- Aerodynamic drag coefficient (Cx)
- 0.33
- Minimum trunk capacity
- 2350 l
- Maximum trunk capacity
- 3981 l
- Curb weight
- 2038 kg
- Braked trailer load (12% slope start)
- 1633 kg
Vehicle dimensions
- Length
- 5144 mm
- Width
- 2000 mm
- Height
- 1750 mm
- Wheelbase
- 3078 mm
- Front track
- 1663 mm
- Rear track
- 1645 mm
- Ground clearance
- 155 mm
- Approach angle
- 14.3 °
- Departure angle
- 18.7 °
- Ramp angle
- 13.9 °
- Turning circle
- 11.92 m
Drivetrain, Brakes and suspension
- Drive
- Front-wheel drive
- Number of gears
- 6
- Front brakes
- Ventilated disc
- Rear brakes
- Disc
- Tire size
- 225/65 R16
- Rim size
- 16
- ABS
- yes
Selected engine version
3.3 V6 (178 KM) Automatic
Gasoline · 2008–2010
- Engine power
- 178 KM
- Torque
- 278 Nm
- Engine displacement
- 3,301 cm³
- Fuel type
- Gasoline
- Maximum speed
- 179 km/h
On this page
Check vehicle history
Basic version information
Dodge Caravan Caravan V- Brand
- Dodge
- Model
- Caravan
- Version
- Caravan V
- Engine
- 3.3 V6 (178 KM) Automatic
- Engine type
- Combustion engine
- Number of doors
- 5
- Start of production
- 2008
- End of production
- 2010
- Body type
- Minivan
- Number of seats
- 7
- Fuel type
- Gasoline
Performance
- Maximum speed
- 179 km/h
- Fuel consumption - Urban cycle
- 13.8 l/100 km
- Fuel consumption - Extra-urban cycle
- 9.8 l/100 km
- Fuel consumption - Combined cycle
- 12.4 l/100 km
Engine
- Engine position
- Front, Transverse
- Engine displacement
- 3301 cm³
- Maximum engine speed
- 5600 obr./min
- Fuel injection system
- Multi-point injection
- Engine type
- Naturally aspirated engine
- Engine configuration
- V-shaped
- Number of cylinders
- 6
- Cylinder bore
- 93 mm
- Piston stroke
- 81 mm
- Compression ratio
- 9.3
- Number of valves per cylinder
- 2
- Engine oil capacity
- 4.7 l
- Coolant capacity
- 12.6 l
- Power
- 178 KM @ 5000 obr./min
- Torque
- 278 Nm @ 4000 obr./min
Volume and weight
- Fuel tank
- 76 l
- Aerodynamic drag coefficient (Cx)
- 0.33
- Minimum trunk capacity
- 2350 l
- Maximum trunk capacity
- 4086 l
- Curb weight
- 1961 kg
- Trailer load without brakes
- 816 kg
Vehicle dimensions
- Length
- 5144 mm
- Width
- 2000 mm
- Height
- 1750 mm
- Wheelbase
- 3078 mm
- Front track
- 1663 mm
- Rear track
- 1645 mm
- Ground clearance
- 155 mm
- Turning circle
- 11.92 m
Drivetrain, Brakes and suspension
- Drive
- Front-wheel drive
- Number of gears
- 4
- Front brakes
- Ventilated disc
- Rear brakes
- Disc
- Tire size
- 225/65 R16
- Rim size
- 16
- ABS
- yes
