Specifications BMW M3 Coupe (E30)

Vehicle photos

Basic information

Brand	BMW
Model	M3
Version	M3 Coupe (E30)
Engine power	195 KM – 238 KM
Years of production	1986 r. – 1990 r.
Body type	Coupé
Number of doors	2
Number of seats	4

Choose engine version, to see Vehicle specifications

Basic version information

Brand	BMW
Model	M3
Version	M3 Coupe (E30)
Engine	2.3 (195 KM) CAT
Engine type	Combustion engine
Number of doors	2
Start of production	1986 r.
End of production	1989 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	230 km/h
Acceleration 0-100 km/h	6.8 s
Fuel consumption - Urban cycle	12.4 l/100 km
Fuel consumption - Extra-urban cycle	7.8 l/100 km
Fuel consumption - Combined cycle	8.8 l/100 km

Engine

Engine model / code	S14Z
Engine position	Front, Longitudinal
Engine displacement	2302 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Engine configuration	Inline
Number of cylinders	4
Cylinder bore	93.4 mm
Piston stroke	84 mm
Compression ratio	10.5
Number of valves per cylinder	4
Engine oil capacity	4.4 l
Coolant capacity	11 l

Volume and weight

Fuel tank	70 l
Aerodynamic drag coefficient (Cx)	0.33
Minimum trunk capacity	420 l
Curb weight	1200 kg
Gross weight	1600 kg

Vehicle dimensions

Length	4345 mm
Width	1680 mm
Height	1370 mm
Wheelbase	2565 mm
Front track	1412 mm
Rear track	1434 mm
Turning circle	11.1 m

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	5
Front suspension	Independent McPherson type
Front brakes	Ventilated disc
Rear brakes	Disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	205/55 R15
Rim size	7J x 15

Basic version information

Brand	BMW
Model	M3
Version	M3 Coupe (E30)
Engine	2.3 (215 KM) CAT
Engine type	Combustion engine
Number of doors	2
Start of production	1989 r.
End of production	1990 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	241 km/h
Acceleration 0-100 km/h	6.7 s
Fuel consumption - Urban cycle	12.4 l/100 km
Fuel consumption - Extra-urban cycle	6.2 l/100 km
Fuel consumption - Combined cycle	7.8 l/100 km

Engine

Engine model / code	S14B23
Engine position	Front, Longitudinal
Engine displacement	2302 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Engine configuration	Inline
Number of cylinders	4
Cylinder bore	93.4 mm
Piston stroke	84 mm
Compression ratio	10.5
Number of valves per cylinder	4
Engine oil capacity	4.4 l
Coolant capacity	11 l

Volume and weight

Fuel tank	70 l
Aerodynamic drag coefficient (Cx)	0.33
Minimum trunk capacity	420 l
Curb weight	1200 kg
Gross weight	1600 kg

Vehicle dimensions

Length	4345 mm
Width	1680 mm
Height	1370 mm
Wheelbase	2565 mm
Front track	1414 mm
Rear track	1435 mm
Turning circle	11.1 m

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	5
Front suspension	Coil spring
Rear suspension	Coil spring
Front brakes	Ventilated disc
Rear brakes	Disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	205/55 R15
Rim size	15

Basic version information

Brand	BMW
Model	M3
Version	M3 Coupe (E30)
Engine	2.5 (238 KM) Sport Evolution
Engine type	Combustion engine
Number of doors	2
Start of production	1990 r.
End of production	1990 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	248 km/h
Acceleration 0-100 km/h	6.5 s
Fuel consumption - Urban cycle	12.5 l/100 km
Fuel consumption - Extra-urban cycle	7.8 l/100 km
Fuel consumption - Combined cycle	8.8 l/100 km

Engine

Engine model / code	S14B25
Engine position	Front, Longitudinal
Engine displacement	2467 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Engine configuration	Inline
Number of cylinders	4
Cylinder bore	95 mm
Piston stroke	87 mm
Compression ratio	10.2
Number of valves per cylinder	4
Engine oil capacity	4.4 l

Volume and weight

Fuel tank	70 l
Aerodynamic drag coefficient (Cx)	0.33
Minimum trunk capacity	420 l
Curb weight	1200 kg
Gross weight	1600 kg

Vehicle dimensions

Length	4345 mm
Width	1680 mm
Height	1370 mm
Wheelbase	2565 mm
Front track	1424 mm
Rear track	1445 mm
Turning circle	11.1 m

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	5
Front brakes	Ventilated disc
Rear brakes	Disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/45 ZR16
Rim size	16

Basic version information

Brand	BMW
Model	M3
Version	M3 Coupe (E30)
Engine	2.3 (200 KM)
Engine type	Combustion engine
Number of doors	2
Start of production	1986 r.
End of production	1989 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	235 km/h
Acceleration 0-100 km/h	6.7 s
Fuel consumption - Urban cycle	11.6 l/100 km
Fuel consumption - Extra-urban cycle	7.5 l/100 km
Fuel consumption - Combined cycle	8.3 l/100 km

Engine

Engine model / code	S14B23
Engine position	Front, Longitudinal
Engine displacement	2302 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Engine configuration	Inline
Number of cylinders	4
Cylinder bore	93.4 mm
Piston stroke	84 mm
Compression ratio	10.5
Number of valves per cylinder	4
Engine oil capacity	4.4 l
Coolant capacity	9 l

Volume and weight

Fuel tank	70 l
Aerodynamic drag coefficient (Cx)	0.33
Minimum trunk capacity	420 l
Curb weight	1165 kg
Gross weight	1540 kg

Vehicle dimensions

Length	4345 mm
Width	1680 mm
Height	1370 mm
Wheelbase	2565 mm
Front track	1412 mm
Rear track	1434 mm
Turning circle	11.1 m

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	5
Front suspension	Independent McPherson type
Front brakes	Ventilated disc
Rear brakes	Disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	205/55 VR15
Rim size	7J x 15

Basic version information

Brand	BMW
Model	M3
Version	M3 Coupe (E30)
Engine	2.3 (220 KM) Evolution
Engine type	Combustion engine
Number of doors	2
Start of production	1988 r.
End of production	1990 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	243 km/h
Acceleration 0-100 km/h	6.7 s
Fuel consumption - Urban cycle	11 l/100 km
Fuel consumption - Extra-urban cycle	7.2 l/100 km
Fuel consumption - Combined cycle	8 l/100 km

Engine

Engine model / code	S14B23
Engine position	Front, Longitudinal
Engine displacement	2302 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Engine configuration	Inline
Number of cylinders	4
Cylinder bore	93.4 mm
Piston stroke	84 mm
Compression ratio	11
Number of valves per cylinder	4
Engine oil capacity	4.4 l
Coolant capacity	11 l

Volume and weight

Fuel tank	70 l
Aerodynamic drag coefficient (Cx)	0.33
Minimum trunk capacity	420 l
Curb weight	1200 kg
Gross weight	1600 kg

Vehicle dimensions

Length	4345 mm
Width	1680 mm
Height	1370 mm
Wheelbase	2565 mm
Front track	1424 mm
Rear track	1445 mm
Turning circle	11.1 m

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	5
Front brakes	Ventilated disc
Rear brakes	Disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/45 ZR16
Rim size	16
