Specifications Toyota Supra IV (A80)

Vehicle photos

Basic information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine power	224 KM – 330 KM
Years of production	1993 r. – 2002 r.
Body type	Coupé
Number of doors	3
Number of seats	4

Choose engine version, to see Vehicle specifications

HISTORY OF VEHICLE

What is VIN?

Basic version information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine	3.0i 24V (224 KM)
Engine type	Combustion engine
Number of doors	3
Start of production	1993 r.
End of production	2002 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	241 km/h
Fuel consumption - Urban cycle	18 l/100 km
Fuel consumption - Extra-urban cycle	9 l/100 km

Engine

Engine model / code	2JZ-GE
Engine position	Front, Longitudinal
Engine displacement	2997 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Valvetrain	DOHC
Engine configuration	Inline
Number of cylinders	6
Cylinder bore	86 mm
Piston stroke	86 mm
Compression ratio	10
Number of valves per cylinder	4
Engine oil capacity	5.2 l
Coolant capacity	7.3 l

Volume and weight

Fuel tank	70 l
Minimum trunk capacity	185 l
Maximum trunk capacity	315 l
Curb weight	1410 kg

Vehicle dimensions

Length	4520 mm
Width	1810 mm
Height	1275 mm
Wheelbase	2550 mm
Front track	1520 mm
Rear track	1525 mm

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	6
Front suspension	Lateral control arm
Rear suspension	Lateral control arm
Front brakes	Ventilated disc
Rear brakes	Ventilated disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/50 ZR16; 245/45 ZR16
Rim size	8.0J x 16; 9.5J x 16

Basic version information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine	3.0i 24V T-turbo (330 KM)
Engine type	Combustion engine
Number of doors	3
Start of production	1993 r.
End of production	2002 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	250 km/h
Acceleration 0-100 km/h	5.1 s
Fuel consumption - Urban cycle	14.6 l/100 km
Fuel consumption - Extra-urban cycle	10.3 l/100 km
Fuel consumption - Combined cycle	11.1 l/100 km

Engine

Engine model / code	2JZ-GTE
Engine position	Front, Longitudinal
Engine displacement	2997 cm³
Fuel injection system	Multi-point injection
Engine type	Twin turbo, Intercooler
Valvetrain	DOHC
Engine configuration	Inline
Number of cylinders	6
Cylinder bore	86 mm
Piston stroke	86 mm
Compression ratio	8.5
Number of valves per cylinder	4
Engine oil capacity	5 l
Coolant capacity	8.9 l

Volume and weight

Fuel tank	70 l
Minimum trunk capacity	185 l
Maximum trunk capacity	317 l
Curb weight	1570 kg
Gross weight	1790 kg

Vehicle dimensions

Length	4520 mm
Width	1810 mm
Height	1275 mm
Wheelbase	2500 mm
Front track	1520 mm
Rear track	1525 mm

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	6
Front suspension	Lateral control arm
Rear suspension	Lateral control arm
Front brakes	Ventilated disc
Rear brakes	Ventilated disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/50 ZR16; 245/50 ZR16
Rim size	8.0J x 16; 9.5J x 16

Basic version information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine	3.0i 24V Turbo (280 KM)
Engine type	Combustion engine
Number of doors	3
Start of production	1993 r.
End of production	2002 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	256 km/h
Acceleration 0-100 km/h	5.1 s
Fuel consumption - Urban cycle	13 l/100 km
Fuel consumption - Extra-urban cycle	9 l/100 km
Fuel consumption - Combined cycle	11 l/100 km
Emission standard	Euro 5

Engine

Engine model / code	2JZ-GTE
Engine position	Front, Longitudinal
Engine displacement	2997 cm³
Fuel injection system	Multi-point injection
Engine type	Twin turbo, Intercooler
Valvetrain	DOHC
Engine configuration	Inline
Number of cylinders	6
Cylinder bore	86 mm
Piston stroke	86 mm
Compression ratio	8.5
Number of valves per cylinder	4
Engine oil capacity	5 l
Coolant capacity	8.9 l

Volume and weight

Fuel tank	70 l
Minimum trunk capacity	185 l
Maximum trunk capacity	315 l
Curb weight	1510 kg
Gross weight	1730 kg

Vehicle dimensions

Length	4520 mm
Width	1810 mm
Height	1275 mm
Wheelbase	2550 mm
Front track	1520 mm
Rear track	1525 mm

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	6
Front suspension	Lateral control arm
Rear suspension	Lateral control arm
Front brakes	Ventilated disc
Rear brakes	Ventilated disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/50 ZR16 ; 245/50 ZR16
Rim size	8.0J x 16; 9.5J x 16

Basic version information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine	3.0i 24V Turbo (280 KM) Automatic
Engine type	Combustion engine
Number of doors	3
Start of production	1993 r.
End of production	2002 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	256 km/h
Acceleration 0-100 km/h	5.1 s
Fuel consumption - Urban cycle	13 l/100 km
Fuel consumption - Extra-urban cycle	9 l/100 km
Fuel consumption - Combined cycle	11 l/100 km
Emission standard	Euro 5

Engine

Engine model / code	2JZ-GTE
Engine position	Front, Longitudinal
Engine displacement	2997 cm³
Fuel injection system	Multi-point injection
Engine type	Twin turbo, Intercooler
Valvetrain	DOHC
Engine configuration	Inline
Number of cylinders	6
Cylinder bore	86 mm
Piston stroke	86 mm
Compression ratio	8.5
Number of valves per cylinder	4
Engine oil capacity	5 l
Coolant capacity	8.8 l

Volume and weight

Fuel tank	70 l
Minimum trunk capacity	185 l
Maximum trunk capacity	315 l
Curb weight	1510 kg
Gross weight	1730 kg

Vehicle dimensions

Length	4520 mm
Width	1810 mm
Height	1275 mm
Wheelbase	2550 mm
Front track	1520 mm
Rear track	1525 mm

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	4
Front suspension	Lateral control arm
Rear suspension	Lateral control arm
Front brakes	Ventilated disc
Rear brakes	Ventilated disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/50 ZR16; 245/50 ZR16
Rim size	16

Basic version information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine	3.0i 24V (224 KM) Automatic
Engine type	Combustion engine
Number of doors	3
Start of production	1993 r.
End of production	2002 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	241 km/h
Fuel consumption - Urban cycle	18 l/100 km
Fuel consumption - Extra-urban cycle	9 l/100 km

Engine

Engine model / code	2JZ-GE
Engine position	Front, Longitudinal
Engine displacement	2997 cm³
Fuel injection system	Multi-point injection
Engine type	Naturally aspirated engine
Valvetrain	DOHC
Engine configuration	Inline
Number of cylinders	6
Cylinder bore	86 mm
Piston stroke	86 mm
Compression ratio	10
Number of valves per cylinder	4
Engine oil capacity	5.2 l
Coolant capacity	8.3 l

Volume and weight

Fuel tank	70 l
Minimum trunk capacity	185 l
Maximum trunk capacity	315 l
Curb weight	1410 kg

Vehicle dimensions

Length	4520 mm
Width	1810 mm
Height	1275 mm
Wheelbase	2550 mm
Front track	1520 mm
Rear track	1525 mm

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	4
Front suspension	Lateral control arm
Rear suspension	Lateral control arm
Front brakes	Ventilated disc
Rear brakes	Ventilated disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/50 ZR16; 245/45 ZR16
Rim size	16

Basic version information

Brand	Toyota
Model	Supra
Version	Supra IV (A80)
Engine	3.0i 24V T-turbo (330 KM) Automatic
Engine type	Combustion engine
Number of doors	3
Start of production	1993 r.
End of production	2002 r.
Body type	Coupé
Number of seats	4
Fuel type	Gasoline

HISTORY OF VEHICLE

Buying a car? Check its history before making a decision!

» Click to check the vehicle history

Performance

Maximum speed	250 km/h
Acceleration 0-100 km/h	5.1 s
Fuel consumption - Urban cycle	14.6 l/100 km
Fuel consumption - Extra-urban cycle	10.3 l/100 km
Fuel consumption - Combined cycle	11.1 l/100 km

Engine

Engine model / code	2JZ-GTE
Engine position	Front, Longitudinal
Engine displacement	2997 cm³
Fuel injection system	Multi-point injection
Engine type	Twin turbo, Intercooler
Valvetrain	DOHC
Engine configuration	Inline
Number of cylinders	6
Cylinder bore	86 mm
Piston stroke	86 mm
Compression ratio	8.5
Number of valves per cylinder	4
Engine oil capacity	5 l
Coolant capacity	8.8 l

Volume and weight

Fuel tank	70 l
Minimum trunk capacity	185 l
Maximum trunk capacity	317 l
Curb weight	1570 kg
Gross weight	1790 kg

Vehicle dimensions

Length	4520 mm
Width	1810 mm
Height	1275 mm
Wheelbase	2500 mm
Front track	1520 mm
Rear track	1525 mm

Drivetrain, Brakes and suspension

Drive	Rear-wheel drive
Number of gears	4
Front suspension	Lateral control arm
Rear suspension	Lateral control arm
Front brakes	Ventilated disc
Rear brakes	Ventilated disc
ABS	yes
Steering system	Rack-and-pinion
Power steering	Hydraulic power steering
Tire size	225/50 ZR16; 245/50 ZR16
Rim size	8.0J x 16; 9.5J x 16
